Precast Mould System Shipped to Jizan, Saudi Arabia

Mana has successfully delivered its self-developed precast concrete mould system to Jizan, Saudi Arabia.

This customised production line was designed based on the local site conditions, environmental factors, and labour costs. It features 80 casting moulds and a multi-layer tunnel kiln system, ensuring stable output and future expansion capabilities to meet various precast component demands.

The line is suitable for producing:

• Sandwich wall panels

• Internal PC wall panels

• Insulated external wall panels

Smart and Efficient Production Process

The production line operates as an automated loop system. Mould pallets move through different workstations via a guided track with drive wheels and positioning sensors.

Key equipment includes:

• Pallet stacker & transfer unit

• Destacker

• Shuttle cart

• Concrete spreader

• Vibration compactor

• Tilting demoulding machine

Curing is completed in a ground-level tunnel kiln with a stepping system, enabling efficient and consistent curing conditions.

Plant Layout Highlights

The plant layout includes the following zones:

• Raw material storage

• Concrete mixing area

• Forming area

• Curing zone

• Demoulding area

• Finished product storage

The layout ensures smooth workflow, minimises material handling, and improves production efficiency.

With years of experience in PC mould systems and plant operations, Mana provides reliable technical support and production solutions. We help clients achieve efficient, high-quality precast production tailored to local conditions.
